Main characteristic:

1. An AC converter control is used for both speed and quantity of glue feeding for which both automatic synchronous tracking and manual control are available.

2. JYT-B hot melt coating machine adopts intelligent PID temperature control system, it can control the temperature exactly and the tolerance is with in 1oC

3. The glue melting oven is coated with the antisticking layer, efficacious prevent the hot melt adhesive against carbonization.

4. Collocate the precision metric gear, make it more steady to produce the adhesive.

5. The high precision of alloy steel spray head has guaranteed high-quality coating result.

6. High-efficiency cooling device insure the applicable range of the basic materials.

Range of application:
This hot melt coating machine is suitable for producing double-side tapes, duct tapes, double-side sponge adhesive tape, clean adhesive tape, masking adhesive tape, Alu. Foil tapes, fabric tapes, shoes materials and medicine dressing tapes, etc.

Technical parameter:

Model JYT-B

Coating Width 400 -2000mm

Coating Weigh 10 -200g / m

Coating Speed 50M /min

Unwind Diameter 1000mm

Rewind Diameter 700mm

Correction Device 1sets

Length 5000mm

Height 1400mm
